Description
- Weight Capacity: 40,000lbs.
- Min. Saddle Height: 7-1/2″
- Max. Saddle Height: 24″
- Hydraulic Lift: 16-1/2”
- Chassis Length: 67″
- Chassis Width: 9-1/8″
- Handle Length: 47-1/2″
- Frame Height: 10-1/2″
- Saddle Diameter: 6-1/2″
- Net Weight: 510lbs.
- Constructed of rugged steel
- Handle lock and release control are located in handle top
- Foot pedal brings saddle up to load quickly
- All cast metal wheels and casters
- The long, low design enables the user to get into those very low work areas
- Designed for heavy duty shop applications
- Meets ansi standard for performance and safety
Proposition 65 Information (California Residents)
