Description
This Tire Changer & Wheel Balancer Combo Includes:
1. Atlas TC229 Tire Changer:
- Rim Clamp/Swing Arm Tire Changer
- Air operated jaws & bead breaker (external air supply required)
- Electric turntable
- Adjustable jaws, three mounting positions
- Metal mount/demount head w/ metal roller or replaceable plastic inserts
- Column mounted inflator box w/ gauge Included
- Filter/Regulator/Lubricator Included
- 20″ Tire Tool Included
- Lube Bucket with Brush Included
- Set of Large Plastic Jaw Covers Included
- Plastic Cover for Bead Breaker Shovel Included
- Multiple Replacement Plastic Inserts for M/D Head Included
- Motorcycle and ATV adapters available (sold separately)
- Built in “Beadblaster”
- Replacement Parts & Wear Items Always in Stock
- 1 Year Manufacturer Warranty (Parts Only)
Specifications:
- External Locking Rim Dimensions (From Narrow Position to Wide Position): 9 3/4″ to 23 1/4″
- Internal Locking Rim Dimensions (From Narrow Position to Wide Position): 11 5/8″ to 25 1/4″
- Maximum Tire Diameter: 39″
- Maximum Wheel Width (Bead Breaker): 13″
- Table Motor: 1 HP
- Turntable Rotating Torque: 885 ft/lbs.
- Bead Breaker: 5500 LB. Force
- Air Requirement: 90-110 PSI (MUST NOT EXCEED 140 PSI)
- Electric Requirement: 110volt
- Shipping Weight: 550 lbs
2. Atlas WB41 Wheel Balancer
- Computer Controlled Spin Balancer
- Raised, Easy to Read Display
- Static and dynamic balancing modes.
- Rapid optimization (OPT)
- Self Diagnosis/Self Calibration
- Display in grams or ounces, in mm or inches
- 4 Centering Cones, Plastic Quick-Nut, Wheel Weight Pliers, & Wheel Measuring Calipers Included
- 1 Year Manufacturer Warranty (Parts Only)
Specifications:
- Max Tire Diameter: 39″
- Rim Sizes (Cars & Light Trucks): 10″ – 32″
- Rim Width: 1 1/2″ – 20″
- Shaft Size: 40mm
- Max Wheel Weight: 150 lbs.
- Balancing Speed: 150 rpm
- Data Entry: All Dimensions Manual
- Measurement: Standard or Metric
- Accuracy: 1 gram
- Weight Position Resolution: 1.4 Degrees
- Self Calibrating: YES
- Motor: 1/4 Horsepower
- Electric Requirement: 110volt
- Shipping Weight: 400 lbs
