Name: Atlas Equipment TCWB-COMBO9 - TC289DAA Tire Changer &amp; WB11 Wheel Balancer Combo
SKU: SK0048738-A
Availability: InStock

Atlas Equipment TCWB-COMBO9 – TC289DAA Tire Changer & WB11 Wheel Balancer Combo

Description

Atlas TCWB-COMBO9 Tire Changer & Wheel Balancer Combo Includes:

Atlas TC289DAA Tire Changer

Rim Clamp/Swing Arm Tire Changer
Left Hand and Right Hand Assist Arms Included
Extra Large Turntable, More Clearance
Built-in “Beadblaster”
Adjustable Bead Breaker Plate
Adjustable jaws, 3 mounting positions
Oiler, Filter, Regulator included (external air supply required)
Plastic Protectors included
Tire Tool, Lube Bucket, and Lube Brush Included
Inflation Box w/ Gauge Included
One Year Manufacturer Warranty

Specifications:

External Locking Rim Dimensions (From Narrow Position to Wide Position): 11 7/8″ to 27 7/8″
Internal Locking Rim Dimensions (From Narrow Position to Wide Position): 13 7/8″ to 29 7/8″
Maximum Tire Diameter: 47″
Maximum Wheel Width (Bead Breaker): 18″
Table Motor: 1 HP
Turntable Rotating Torque: 885 ft/lbs.
Bead Breaker: 5500 LB. Force
Air Requirement: 90-110 PSI (MUST NOT EXCEED 140 PSI)
Electric Requirement: 110volt
Shipping Weight: 620 lbs

Atlas WB11 Wheel Balancer

Computer Controlled Spin Balancer
Static and dynamic balancing modes.
Rapid optimization (OPT)
Self Diagnosis/Self Calibration
Display in grams or ounces, in mm or inches
4 Centering Cones, Plastic Quick-Nut, Wheel Weight Pliers, & Wheel Measuring Calipers Included
One Year Manufacturer Warranty

Specifications:

Max Tire Diameter: 39″
Rim Sizes (Cars & Light Trucks): 10″ – 32″
Rim Width: 1 1/2″ – 20″
Shaft Size: 40mm
Max Wheel Weight: 150 lbs.
Balancing Speed: 150 rpm
Data Entry: All Dimensions Manual
Measurement: Standard or Metric
Accuracy: 1 gram
Weight Position Resolution: 1.4 Degrees
Self Calibrating: YES
Motor: 1/4 Horsepower
Electric Requirement: 110volt
Shipping Weight: 355 lbs

This combination package includes the Atlas® TC289 rim-clamp swing arm tire changer & the Atlas® WB11 computerized spin balancer. This combination is perfect for farms, homeowners, and all sizes of shops looking to change and balance tires. Both machines are 110volt operated and both are CE approved.
