Description
- Air-powered, easy on the operator, and easy on your bottom line.
- The Branick 5130 tire spreader is typically used for both passenger and light truck tires when you need a little more from a spreader.
- It comes with a convenient tool tray so everything is within easy reach.
- Compact footprint to minimize space required
- Debris blocking cylinder guard
- The stable base can be bolted to the floor, and it has foot operated controls for spreading the tire.
- Includes easy spring-loaded pin adjustment and a high-impact industrial light mounted on a flexible arm, making it easier for inspection and repair.
- It uses an LED bulb that is RMA-compliant, meaning our bulbs emit a minimum of 200′ candles.
- One Year Manufacturer Warranty.
- Made In USA.
- Tire Cross Section: Up to 14 inches
- Bead Diameter: Up to 22.5 inches
- Base Dimensions: 18 x 25 inches
- Overall Dimensions: 27 x 25 x 40 inches
1) Move spread hooks out from tire platform.
2) Position tire on tire platform. Steady tire with hand and insert spread hooks over tire beads.
3) Adjust spread hooks to proper height for tire being repaired. To adjust spread hooks, pull quick pin out, move spread hook arm up or down to one of the four adjustment holes and release
quick pin. Both spread hooks must be adjusted to same height.
4) Spread tire to desired width using foot valve and move light for best visibility. If tire is lifted off spread platform when spread, spread hook arms are positioned too high and should be lowered.
5) To rotate tire to new position, release pressure on spread hooks and rotate tire on rollers.
6) After inspection and repairs are complete, move light away from tire, release spread hooks using foot valve and remove spread hooks from tire bead.
