Description
- Advanced Dual-Gas (R134A & R1234YF) Refrigerant Recovery, Recycle & Recharge Machine
OILLESS COMPRESSOR FOR RAPID RECOVERY
- Designed for high-capacity applications, our 2/3 hp oilless compressor not only decreases recovery time but also enables a more thorough internal flush, ensuring your systems are cleaner and more efficient.
- Increased service life over competitor oiled compressors
- Eliminates failure issues due to improper oil filling of traditional compressors
- Unique design enables recovery of liquid refrigerant
EFFORTLESS TRANSPORT AND STORAGE
- The removable tank eliminates the need for scale locks, and each refrigerant management center includes two 30lb tanks included with the MSX3030 model, and hose management built into the handle assembly on all models.
BUILT TO LAST
- Each refrigerant management center is constructed of a heavy-duty, durable welded steel frame, designed to withstand the harshest shop environments.
SMART TECHNOLOGY AT YOUR FINGERTIPS
- Stay connected with Bluetooth® and Wi-Fi on board, as well as a 7″ color touchscreen with enhanced navigation. Wireless printing is enabled for seamless record-keeping.
- 7” Color touch screen control panel allows quick access to all functions from the main screen
- Bluetooth/Wireless Adapters #TACI100 (Optional) that enable complete pre- and post-service health checks of the system
- Refrigerant Management System monitors filter life and refrigerant usage
- Fast guided refrigerant changeover for the MSX3030 multi-refrigerant machines
- Supports multiple languages/UOM
- Includes vehicle database for oil and refrigerant charging capacities
10” FOAM FILLED TIRES
- 10″ inch foam-filled tires allows you to glide over shop floor obstacles effortlessly.
- No flat, maintenance-free tires
- Larger tire diameter for increased mobility
- Manufacturer Warranty:
- One Year Parts and Labor
- Two Years Parts Only
- Three Years Compressor
Experience the pinnacle of refrigerant management with the MSX3030, setting a new standard in Refrigerant Recovery, Recycling, and Recharge (R) Management Centers. Engineered to elevate your workflow with unmatched efficiency and precision performance, the MSX3030 surpasses expectations. Equipped with a high-capacity oilless compressor, it accelerates recovery time by up to 30% faster than competitors, validated by rigorous internal testing. Seamlessly navigate operations with the intuitive 7” Color touch-screen display, ensuring effortless interaction and usability. Plus, with its integrated refrigerant identifier and compatibility with multiple refrigerants, including R-134a and R-1234yf, the MSX3030 is the ultimate solution for streamlined refrigerant management. Experience MSX precision performance with increased productivity in the MSX3030.
Specifications:
- Power: 115V 60Hz
- Compressor: 2/3 HP twin cylinder oilless
- Vacuum pump: 2-Stage, 2 CFM, 1/3 HP
- Gauges: 3.5” Low-side, 30 in/Hg to 250 psi; High-side, 0 to 600 psi
- Hoses: 10 Ft. (3.0 m), Barrier Type
- Refrigerant: R-134a/R-1234yf
- Maximum recovery rate: Up to 1 Lb (0.453 kg) per minute
- Storage tank: MSX3030, includes 2-30 Lb. tanks), upgradable to 50 Lb.
- Display: 7” Color Touch-Screen
- Construction: Heavy-duty Steel Frame Construction
- Operating temp range: 50°F to 122° (10°C to 50°C)
- Operating humidity range: 0% to 95% (Non-Condensing)
- Dimensions: 43.6” x 22.6” x 28.9”
- Gross weight: 208 lb. (including packaging)
View CPS MSX3030 Recovery Machine User Manual
