Description
- The Forney 250 AMP spool gun allows practically any MIG welder to weld aluminum.
- Great for first time users and experienced professionals alike, this spool gun was designed around simplicity, reliability, and performance. This lightweight and compact unit delivers top tier ergonomics and comes standard with an impressive 20-foot all-in-one power and gas cable, resulting in an extra-large working area.
- Optimized to use TWECO style consumables and .035” wire; this spool gun can also run a variety of wire diameters from .030” to .047”. This spool gun can weld a variety of thicknesses from thin sheet metal to ½” thick plate.
- Compatible with Euro Style Forney and Forney Pro MIG and Multi-Process (MP) machines.
Specifications:
- Rated Output and Duty Cycle: 200 AMP @ 60% Duty Cycle
- Maximum Output Amperage: 250 AMPs (DC Output Only)
- Primary (Input) Volts: 0-12 V
- Wire Diameters: .030” (0.76 mm) to .047” (1.2 mm)
- Wire Feed Speed: 1,000 Inches per Minute (IPM)
- Cable Length: 20’ (6.1 m) All-in-one power/gas cable
- Consumables: 14H Series TWECO style
- Dimensions: 16” (406 mm) x 12” (304 mm) x 3.5” (89 mm)
- Weight: 11 lbs. (5.00 kg) (Includes Cable)
