Description
- Powerful 3/4 HP motor
- Requires a dedicated 20-amp or two separate 15-amp circuits
- 13’ heavy duty 3/4” service hoses
- 10 gallon transmission fluid capacity with easy to read level sight glass
- 8 GPM flow rate
- Low fluid heater cutoff float switch
- 60 micron cleanable screen filter
- Reverser valve allows easy flow reversal without changing service hoses during and between flush cycles
- Select from two preset flush patterns or manual air purge to additionally agitate during flushing and to clear service lines and cooling system after flushing
- 1500 watt heater set at 140°F
- Temperature gauge
- Flush with or without heat
- Two non-bypass spin-on magnetic replaceable system filters (P/N 40300272)
- Hour run meter
- 10” semi-pneumatic tires
- 1 Year Manufacturer Warranty
The Flo-Dynamics TTCF-9B Base Unit High Flow Hydraulic System Flusher will flush and clean transmission coolers and lines or any hydraulic system of contamination, sludge and varnish deposits, and particles from a failed transmission.
The TTCF-9B has a flow rate of 8 GPM to clean heavy duty transmission cooling systems requiring high flow rates.
Using the same hydraulic fluid as the hydraulic system being flushed and cleaned, select from two preset air injected scrubbing action flush patterns, or perform a manual flush. Check system cleanliness with the reusable 60 micron screen filter.
The TTCF-9B has a preset heater that heats to 140°F in 45 minutes. Two manually-selected flush patterns designed to inject the optimal amount of air creating an agitating scrubbing action to remove trapped debris and solidified waxy varnish.
Easily switch flow direction without removing service hoses during and between flush cycles with the reverser valve. Flush with or without heat with using separately controlled motor/pump and heater switches.
