Description
- Refined cartridge machining process creates an improved surface finish extending the longevity of the pump life
- Expanded internal oil path creates less friction and ultimately less heat
- Upgraded seals insure maximum vacuum
- U.S. designed and tested
- Easy grip handle
- Gas ballast valve helps prevent oil contamination caused by high moisture
- Easily removable vapor discharge/oil fill port
- Large oil level sight glass with max/min level indicator
- Easily accessible oil drain valve
- Thermally protected motor with on/off rocker switch
- Manifold valve isolates pump from the system when testing for leaks. Includes 3 inlet ports, 1/4?, 3/8? SAE and 1/2? ACME
- High volume fan provides cool air to motor and pump
- Check valve prevents oil back-flow
- Cooling fins keep temperature cooler during extended operation
- Large, light weight reinforced base for stable positioning
SPECIFICATIONS:
- Stages: 2
- Free air displacement: 170 lit/min (60Hz), 142 lit/min (50Hz)
- Ultimate vacuum: 15 microns
- Motor: 1/2 HP
- Pump speed: 1440 RPM
- Electrical specs: 220 V, 50/60 Hz
- Power: 220V cable (schuko)
- Weight: 11.22 kg (24.75 lbs)
- Dimensions: 37.9 x 16.7 x 27.5 cm
